Bespoke Access Panels
1 YEAR Limited Warranty
FREE DELIVERY on orders over £199 (exclusions apply)
30 DAY Returns Policy

Custom Access Panels: Tailor-Made Solutions Managed by Experienced Project Managers

When it comes to Access Panels, one size doesn't fit all. Trade Counter Direct offers a bespoke, made-to-measure service that caters to your specific requirements, whether you need a single custom panel or are overseeing a large-scale project. Managed by a team of experienced project managers, our made-to-measure service ensures that your custom panels are not only of the highest quality but also delivered on time and within budget.

Our Standard Features

Our made-to-measure panels are:

  • Manufactured in the UK from 0.9mm thick Zintect steel for both door and frame.
  • Versatile, designed for installation in both walls and ceilings.
  • Equipped with extending fixing tabs for easy installation.
  • Available in non-fire rated and 1-hour fire rating options.
  • Fitted with a fixed pivot hinge system.
  • Secured with a budget lock and a square-headed tee-key (provided free of charge).
  • Powder-coated in RAL 9010 30% Gloss.
  • Offered in either a Beaded or Picture frame in 25mm or 50mm sizes.
  • Certified for fire resistance up to 1200x600mm in both ceiling and wall applications.

Customisation Options

If our standard features don't meet your needs, we offer further customization options:

  • Extended Fire Rating: Up to 4 hours, including panels fire-rated from both sides.
  • Locking Options: A variety of lock types to choose from.
  • Colour Customisation: Specify any RAL colour.
  • On-Site Painting: We offer a powder-coated primer for on-site painting.
  • Antibacterial Coating: To help reduce the spread of germs.
  • Acoustic Rating: From 30dB to 46dB.
  • Sealing: Dust, air, and smoke-sealed panels.

Measuring Guide

Please note that we deduct 7mm from the sizes ordered to allow for tolerance.

Why Choose Our Made-to-Measure Service?

  1. Personalised Service: Our experienced project managers handle everything from production to delivery.
  2. Quality Assurance: Manufactured to the highest standards in the UK.
  3. Tailor-Made: Customised to your exact specifications.
  4. Flexibility: From individual panels to large-scale projects, we cater to all needs.

Can't find the exact size or specification you need? Contact our sales team at [email protected] and we'll be more than happy to assist you with your specific requirements.



Access Panel Quote Banner

Custom Metal Access Panel Quote

Complete this form and we'll quote within 24 hours. (Monday - Friday 9am- 4pm, excludes bank holidays)

NB. We can only ship custom panels to Mainland UK.

We can custom make single Access Panels (not plastic panels) for one-off jobs all the way up to project managing large-scale construction projects.

If you have schematics or plans please email our team directly and we'll help with the process: [email protected]

Dimensions A & B are the Door Size.

E &F are the structural opening size which is 7mm greater than the door size.

Therefore a 300 x 300 mm Door Size will have a structural opening of 307 x 307 mm.

C & D are an additional 25mm on all sides on top of the structural opening.

This is an example of a
Picture Frame Access Panel

This is an example of a
Beaded Frame Access Panel
This is an example of a
Plasterboard Access Panel

Your Details


Access Panel Details


Please Add Notes Accordingly, Specifications & Questions

Access Panel Details Two


Please Add Notes Accordingly, Specifications & Questions

Access Panel Details Three


Please Add Notes Accordingly, Specifications & Questions

Access Panel Details Four


Please Add Notes Accordingly, Specifications & Questions

Access Panel Details Five


Please Add Notes Accordingly, Specifications & Questions

Access Panel Details Six


Please Add Notes Accordingly, Specifications & Questions

Access Panel Details Seven


Please Add Notes Accordingly, Specifications & Questions

Access Panel Details Eight


Please Add Notes Accordingly, Specifications & Questions

Access Panel Details Nine


Please Add Notes Accordingly, Specifications & Questions

Access Panel Details Ten


Please Add Notes Accordingly, Specifications & Questions

Custom Access Panels: Tailor-Made Solutions Managed by Experienced Project Managers

When it comes to Access Panels, one size doesn't fit all. Trade Counter Direct offers a bespoke, made-to-measure service that caters to your specific requirements, whether you need a single custom panel or are overseeing a large-scale project. Managed by a team of experienced project managers, our made-to-measure service ensures that your custom panels are not only of the highest quality but also delivered on time and within budget.

Our Standard Features

Our made-to-measure panels are:

  • Manufactured in the UK from 0.9mm thick Zintect steel for both door and frame.
  • Versatile, designed for installation in both walls and ceilings.
  • Equipped with extending fixing tabs for easy installation.
  • Available in non-fire rated and 1-hour fire rating options.
  • Fitted with a fixed pivot hinge system.
  • Secured with a budget lock and a square-headed tee-key (provided free of charge).
  • Powder-coated in RAL 9010 30% Gloss.
  • Offered in either a Beaded or Picture frame in 25mm or 50mm sizes.
  • Certified for fire resistance up to 1200x600mm in both ceiling and wall applications.

Customisation Options

If our standard features don't meet your needs, we offer further customization options:

  • Extended Fire Rating: Up to 4 hours, including panels fire-rated from both sides.
  • Locking Options: A variety of lock types to choose from.
  • Colour Customisation: Specify any RAL colour.
  • On-Site Painting: We offer a powder-coated primer for on-site painting.
  • Antibacterial Coating: To help reduce the spread of germs.
  • Acoustic Rating: From 30dB to 46dB.
  • Sealing: Dust, air, and smoke-sealed panels.

Measuring Guide

Please note that we deduct 7mm from the sizes ordered to allow for tolerance.

Why Choose Our Made-to-Measure Service?

  1. Personalised Service: Our experienced project managers handle everything from production to delivery.
  2. Quality Assurance: Manufactured to the highest standards in the UK.
  3. Tailor-Made: Customised to your exact specifications.
  4. Flexibility: From individual panels to large-scale projects, we cater to all needs.

Can't find the exact size or specification you need? Contact our sales team at [email protected] and we'll be more than happy to assist you with your specific requirements.
